CR2354 3V Button Battery 560mAh Primary Lithium Battery With Solder Tags For Rice Cooker

CR2354 3V Button Battery 560mAh Primary Lithium Battery with Solder Tags for Rice Cooker

CR2354 Button Cell Features & Benefits

The CR2354 battery is a high-performance primary lithium button cell battery. It features a compact and flat design, measuring 23mm in diameter and 5.4mm in thickness. With a nominal voltage of 3V, it provides a stable and reliable power source for numerous small electronic devices. This battery offers a relatively high energy density, enabling it to supply power for an extended period. It has a low self-discharge rate, which means it can retain its charge even when not in use for a long time. The CR2354 is also environmentally friendly, containing no mercury or cadmium. It is widely used in applications such as watches, calculators, key fobs, and some medical and fitness trackers, thanks to its excellent performance and durability under different operating conditions.

CR2032 Button Cell with Solder Tags Specifications

Part number	CR2354
Nominal voltage	3V
Nominal capacity	560mAh
Standard Discharge Current	1mA
Peak Pulsing Current	20mA
Annual Self-Discharge Rate	≤3%
Dimensions	Diameter(Max.)	23.0mm
	Height(Max.)	5.4mm
Weight	Approx. 6.1g
Working Temperature Range	-20℃ to +60℃
CR2354 Cell Draft:
CR2354 Cell with Solder Tags Draft:

CR2032 Button Cell with Solder Tags Applications

The CR2354 battery finds extensive applications in various fields. In the realm of consumer electronics, it powers small devices like wristwatches, calculators, and digital thermometers. It is also commonly used in portable medical devices such as blood glucose meters and heart rate monitors due to its reliable power supply. In the automotive industry, it serves in key fobs for keyless entry systems. Moreover, it plays a crucial role in some wearable fitness trackers and smart sensors, enabling them to function accurately and continuously. Additionally, it can be found in certain toys and small remote control devices, providing the necessary energy for their operation.
